14.8V 3200mAh 18650 Lithium Ion Battery LG Battery for Medical Device with SMBUS Communication

2020-08-25 06:51

14.8V 3200mAh 18650 Lithium Ion Battery LG Battery for Medical Device with SMBUS Communication

  • Model number:AIN14/8-3200
  • Nominal voltage:14.8V
  • Nominal capacity:3200mAh
  • Battery cell:18650/3200mAh/3.7V
  • Dimension:81*76*10.1mm(Max)
  • Application: medical power supply

Product Detail

Cell model:18650/3200mAh/3.7V

Battery specification: 18650-4S1P/14.8V/3200mAh

Nominal voltage:14.8V

Nominal capacity:3200mAh

Charging voltage: 16.8V

Charging current: ≤2.5A

Discharging current: 3A

Instant discharging current: 5A

End-off voltage: 12V

Internal resistance: ≤400mΩ

Battery weight: 210g

Product dimension: 81*76*10.1mm(Max)

Charging temperature:0~45℃

Discharging temperature: -20~55 ℃

Storage temperature: -20~45 ℃

Lithium-ion battery protection: short circuit protection, overcharge protection, over-discharge protection, overcurrent protection, equilibrium, Sumbus communication, etc.

Application field: medical power supply

Product features

  1. Current: maximum sustainable discharge current is 5A.
  2. Data communication management: adopt imported software management chip, SMBus communication function, precise data transmission and accurate temperature control so as to try our best to eliminate the security risks.
  3. Battery characteristics: adopt imported LG battery with ultra large capacity.
  4. The battery pack has long cycle life, which conforms to the principle of low carbon, energy conservation and environmental protection.



Note: We are a battery manufacturer. All products do not support retail, please contact us for product prices!
