ALL IN ONE Rechargeable Battery Lifepo4 32650 12V 7Ah Battery Pack

2021-06-07 01:06

Specification





Electrical Characteristics

Nominal Voltage12.8v
Nominal Capacity7Ah @ 0.2C
Energy89.6Wh
Internal resistance ≤90mΩ
Cycle Life>2000 cycles @ 0.2c charge/ discharge at 100%DOD,End of life 70% capacity
Months Self discharge≤3.5% per month at 25℃




Standard Charge

Charge voltage14.6±0.2V
Charge Mode( CC/CV)At 0℃~45℃ temperature, charged to 14.6v at constant current of 0.2C5A, and then, changed continuously with constant voltage of 14.6v until the current was not more than 0.02C5A
Charge current1.4A
Max.Charge current3.5A




Standard Discharge

Discharge current1.4A
Max.continuous current7A
Max. Pulse current20A (<3S)
Discharge cut-off voltage10.0V




Environmental

Charge Temperature0℃ to 45 ℃
Discharge Temperature-20℃ to 60 ℃
Storage Temperature0℃ to 45 ℃
Water Dust ResistanceIP55




Mechanical

Cell & MethodIFR26650 N35,4S2P
Plastic CaseABS
Dimension (L*W*H*TH)151*65*94*100mm
WeightApprox. 1.06KG
TerminalF2

Feature

1. Safety: safest Lithium battery, CE UL approved, built-in PCM/BMS
2. Clean and Green energy, no toxic material contained
3. Long life cycle:> 2000 times, 6-8 times of lead acid battery
4. No memory effect, highly efficient, charge anytime
5. Small size and light weight: 1/2 size& weight of lead acid battery
6. Good performance at high temperature
7. Low self-discharge rate: < 3% monthly

Advantages for ALL IN ONE Lithium Iron Battery

Energy density is high The volume and weight of lithium battery is 1/3 to 1/4 of the traditional lead acid battery with the same capacity.
Energy conversion rate is 15% higher than that of a traditional lead acid battery, the advantage of energy saving is obvious. Self-discharge rate < 2% per month.

Broad temperature adaptability Products perform well at a temperature of -20°C to 60°C, without air conditioning system.

Cycle durability for a single cell is 2000 cycles 100% DOD, which is 3 to 4 times more than the cycle durability of a traditional lead acid battery.

Higher discharge rate, faster charging and discharging When there is a need for backup power supply for a period of 10 hours or less, we could reduce up to 50% of the capacity configuration, comparing to lead acid battery.

High security Our lithium battery is safe, electrochemical materials are stable, no fire or explosion under  extreme conditions such as high temperature, short circuit, drop impact, piercing, etc

Application

Electric Vehicles,electric mobility

Solar/wind energy storage system

UPS, backup power

Telecommunication

Medical equipment

Lighting and so on

Our Factory

Why Choose ALL IN ONE?
1) Nearly 11 years leading manufacturer,established in 2010. Factroy size: 10000 square meter
2) Strict management system and quality control, 100% inspection.Factories are satisfied with ISO 9001 & ISO
14001, products with CE/RoHS/TLC etc approval.
3) A professional experienced team to provide you high-quality service.All enquires will be replied in 24 hours.
4) Competitive price help you  to occupy more market share
5) 20000KWH production capacity to guarantee the best deliver time
6) 1-3 years warranty policy, up to now, our product defective rate is under 0.4%.

Packing And Shipping

FAQ

Q: Are you trading company or manufacturer?
A: We are ALL IN ONE original factory.

Q: Can I have samples to test? And what is lead time for sample order?
A: Yes,we can supply samples,the leadtime for samples is 3-5 days.and buyer pay for sample cost and shipping cost.

Q: Do you provide after-sales serive?
A: Yes,the warranty is 12 months, if any quality problems on our side in this period, we can send new one as replacement.

Q: Do you accept OEM/ODM?
A: Yes,it is avaliable.

Q:Are you battery real capacity?
A: All of our battery cells with Grade A,100% new and real capacity.

Q: What kind of certificates do you have?
A: We can provide CE,ROHS,FCC,IEC62133,MSDS,UN38.3 if your order quantity is big.

Q:Do you have MOQ ?
A:No limited. Small order also welcome.More quantity has better price, we will check the best price for you.

Q: What is your term of payment?
A: We adopt T/T and Paypal payment way and so on.

Note: We are a battery manufacturer. All products do not support retail, please contact us for product prices!
