|Nominal Battery Energy||3900wh|
|Months Self Discharge||<3%|
|DC Normal Charge Voltage||54.75±1Vdc|
|Charge Mode||0.2C to 54.75V, then 54.75V,charge current to 0.02C (CC/CV)|
|Recommended Charger Current||≤50A|
|Allowed Max. Charge Current||50Adc|
|Charge Cut-off Voltage||54.75±1Vdc|
|Continuous Discharge Current||50A|
|Allowed Max. discharge current||100A (option:100Adc)|
|Rang of DC discharge voltage||37.5V-54.75Vdc|
|Charge Temperature||0℃ to 45℃ (32℉ to 113℉) @60±25% Relative Humidity|
|Discharge Temperature||-20℃ to 60℃ (-4℉ to 140℉) @60±25% Relative Humidity|
|Storage Temperature||0℃ to 40℃ (32℉ to 104℉) @60±25% Relative Humidity|
|Enclosure Protection Level||IP67|
2.Use of Iron(Fe) as a cathode material
3.Higher discharge current
4.Do not explode under extreme conditions and weight less
1.Extremely high rate capability
2.Safe lithium battery
3.Good storage characteristics
4.Good high temp performance
5.Long cycle life to 2000 times
6.High capacity & light weight
8.No memory effect
We can provide you with customized services
Customized 7.4V-12V-24V-36V-48V-52V-60V-72V...LITHIUM BATTERY PACK
The capacity and dimension can customize according to your request:
1.Customized battery size and shell material
2.Customized BMS charging and discharging current
3.Customized connect plug and socket, connector wire
|AIN Lithium Battery Pack Main Applications|
|Electric propelling applications||engine starting battery; Slow Speed Car; intellectual robots; electric bicycle/motorcycle/scooter; golf trolley/carts/ sightseeing car; power tools.|
|Energy storage||solar and wind power system; city on/off grid; community and family, RV Caravan, Marine yachts.|
|Back-up system and UPS||Telecommute base, CATV-system, computer server center, medical instrument, military equipment.|
|Other applications||security and electronics; mobile POS, mining light/torch/LED light/emergency light.|
WHY CHOOSE US?
1.Our company has 13 years experience in battery R&D,producing and the overseas marketing.
2.Flexible customizing and Manufacturing
3.6,000,000Ah monthly production capacity
4.Each process for making battery were under strict management and control,all of the battery were under full inspection before delivery.
5.With professional R&D team, experienced workers and advanced requirements, we are determined to provide you high-quality battery.
6.Support prompt shipment and sample quality products,track the cargo in time after delivery.More than one year Guarantee,we will give instruction for how to use our products.
Q: What is your warranty?
A: We guarantee the quality before the item is shipped. The warranty will be offered based on different type of battery. Any damages caused by improper use are not covered by our warranty.
Q: What is delivery time if we place an order?
A: It depends order quantities. Usually, we can deliver goods within 3 -5 working days for small orders, for more QTY. order, let's confirm when you place offical order.
Q: Are your factory or trading company?
A: We are professional lithium-ion rechargeable batteries manufacturer with our own factory and brand. We provide all kinds of OEM/ODM services for clients around globe.
