Deep cycle lithium ion battery Lifepo4 24v 200ah solar storage battery 3500+ cycles li ion battery pack

2021-06-17 05:53

Specification

Electrical Characteristics	Nominal Voltage	24V
	Nominal Capacity	[email protected]
	Energy	2560Wh
	Internal Resistance	≤35mΩ
	Cycle Life	2000 Cycles @ 0.2C Charging/Discharging ,Until 70% Capacity
	Self Discharge	≤3.5% per month at 25℃
Standard Charging	Max.Charging Voltage	14.0~14.6V
	Charging Mode	At 0℃~45℃ temperature, charged to 14.6V at a constant current of 0.2C, and then,changed continuously with constant voltage of 14.6V until the current was not more than 0.02C
	Charging Current	50A
	Max.Charging Current	120A
Standard Discharging	Discharging Current	50A
	Max. Continuous Current	120A
	Max.Pulse Current	250A(<3S）
	Discharging Cut-off Voltage	20.0
Operating Condition	Charge Temperature	0℃ to 45℃(32℉ to 113℉) @60±25% Relative Humidity
	Discharge Temperature	-20℃ to 60℃(-4℉ to 140℉) @60±25% Relative Humidity
	Storage Temperature	0℃ to 45℃(32℉ to 113℉) @60±25% Relative Humidity
	Water Dust Resistance	IP55
Structure	Cell & Format	32700,8S16P
	Casing	Plastic
	Dimension(LWH*TH)	522238217*217
	Weight	Approx.25Kg
	Terminal	M8

Product Advantage

◆ Using the technology of lithium iron phosphate cell, superior safety, thousands of cycles, 100%DOD, under normal conditions.

◆ Built-in automatic protection for over-charge, over discharge, over current and over temperature.

◆ Free of maintenance .

◆ Internal cell balancing.

◆ Lighter weight: About 40% ~50% of the weight of a comparable lead acid battery.

◆ Can be charged using most standard lead-acid charges (set).

◆ Wider temperature range:-20℃~60℃.

◆ Support for Series application expansion (up to 51.2V) and two in parallels.

Application

◆ UPS
◆ Solar &Wind Power System
◆ Golf Cart
◆ Electric Vehicle , E-bike, E-rickshaw etc.
◆ Lighting

Products are widely used in Mountain power generation,Communication base,Street light etc.

Our Factory

We can provide you with customized services Capacity, size, application, etc can customize according to your request:

1.Customized battery size and shell material

2.Customized BMS charging and discharging current

3.Customized connect plug and socket, connector wire

Packing And Shipping

FAQ

Q1: Are you factory or trading company ?
A1: ALL IN ONE is a professional manufacturer of a full of line Ni-MH, Li-ion, and LiFePO4 batteries. We can provide all kinds of OEM / ODM services for clients around globe. With 11 years of research & development and manufacturing experience, we are very professional on quality control and after-sale services.

Q2: Can I just try samples for the first order ?
A2: Trail order is acceptable. We welcome sample order to test and check quality, but we don't provide free samples.

Q3: What about the lead time ?
A3: Sample needs 5~7 days, mass production needs 2~4 weeks, It depends on your order quantity.

Q4: What is your shipping method ?
A4: We suggest sample & small order to be shipped to destination through our shipper partner who has excellent UPS/DHL/TNT/FedEx service. The shipping cost and delivery time will be determined according to the quantity of the goods and delivery address.Airline and sea shipping is also optional.

Q5: Are your battery real capacity ?
A5: All of our battery cells with grade A, 100% new and real capacity. If you need B grade cells, please contact us separately for the price and lead time as well as discount.

Q6: What percent of capacity battery charged before shipment ?
A6: Normally 10% or so, It will be safe when shipping.

Q7: Do you provide after-sale services ?
A7: Yes, the warranty is 12 months.

Q8: How to proceed with an order.
A8: Firstly let us know your requirements or applications. Secondly we will quote according to your requirements or our suggestions. Thirdly customer confirms the sample and places the deposit for formal order, then we can arrange the production.

Q9: Would you accept to use our Logo ?
A9: Yes, It is available. But we have MOQ for customized products. Please inform us formally before our production and confirm the design firstly based on our samples.

Q10: What kind of certificates do you have ?
A10: We have CE, CB, UL, BIS, RoHS, IEC62133, ISO14001, CQC, SQP, WERCS, MSDS, UN38.3 and so on.

Note: We are a battery manufacturer. All products do not support retail, we only do B2B business.please contact us for product prices!
