ALL IN ONE 12.8V 250Ah Electric Scooter Inverter Lithium Ion Battery

2022-02-26 02:21

Product Description

Cyclen provides one-stop services and fully-integrated battery solution to meet your specific needs. The products we display don't represent the limitation of us.

In addition to the battery shape and temperature conditions, we can customize specifications and BMS: voltage, capacity , charge current, discharge current and etc.If you are interested in our products, please don't hesitate to contact us at any time.
 Item
General Parameter
Remark
Model
IFR 3.2V 120Ah
Casing material for single cell
Nickel plated steel
Standard capacity(0.2C5A)
250Ah
Rated voltage
12.8V
Work voltage:3.20V
Max.Charge voltage
14.6V
Single Ave. charge Voltage 3.65V
Cut-off voltage
10V
Single Ave. Discharge Voltage 2.5V
Standard charge current
50A
0.2C
Charging Time
About 5h
Max Continuous discharge current
100A or 175A
Peak discharge current
200A or 320A
Battery dimension
495*268*219mm
Shell Material
ABS
Total weight(Approx.)
About 28kg
Impedance(Max, at 1000Hz.)
≤ 45mΩ
Charge Method (CC/CV)
Standard
0℃~45℃ (32℉~113℉)
discharge
-20℃~65℃ (-4℉~140℉)
storage
-20℃~45℃ (-4℉~176℉)

Main Features
1. Lighter in weight, heavier on power
2. Use a grade prismatic cells. More than 3000 cycle times.
3. Max discharge continuous current 175A, peak 320A.
4. Maintenance free. Can connect in parallel and series.
5. Safer performance. Our batteries have passed different safety tests.
6. IP65 Waterproof ratings.

Built in BMS overall protection
1.Over charged protection
2.Over discharged protection
3.Thermal protection
4.Over load protection
5.Over current protection

Deep Cycle Applications
Widely used in RV, camping car, golfcart, sightseeing car, marine, yacht, solar backup etc

Our Projects

Our Factory

Why Choose Us
1. We are a supplier with 10 years' experiences.All our items come with high quality and good after-sale service.
2. Professional, technical, production & service team for your service.
3. Stable Quality – Come from superior material supplier and perfect quality control system.
4. Competitive price than any other suppliers.
5. 7/24 service for you, all the question will be dealed within 6 hours.

  Packing and Shipping

FAQ

Q1. Can I have a sample order for Battery?

A: Yes, we welcome sample order to test and check quality.

Q2. What about the lead time?

A:Sample needs 5-10 days, mass production time needs 25-30 days.

Q3. Do you have any MOQ limit for Battery?

A: Low MOQ, 1pc for sample checking is available

Q4. How do you ship the goods and how long does it take to arrive?

A: We usually ship by UPS, TNT... It usually takes 3-5 days to arrive. Airline and sea shipping also optional.

Q5. How to proceed an order for Battery?

A: Firstly let us know your requirements or application.Secondly We quote according to your requirements or our suggestions.Thirdly customer confirms the samples and places deposit for formal order.Fourthly We arrange the production.

Q6. Is it OK to print my logo on Battery?

A: Yes. Please inform us formally before our production and confirm the design firstly based on our sample.

Q7: Do you offer guarantee for the products?

A: Yes, we offer 1-2 years warranty to our products.

Q8: How to deal with the faulty?

A: Firstly, Our products are produced in strict quality control system and the defective rate will be less than 0.2%.
Secondly, during the guarantee period, we will send new batteries with new order for small quantity. For defective batch products, we will repair them and resend them to you or we can discuss the solution including re-call accordingto real situation.

Note: We are a battery manufacturer. All products do not support retail, we only do B2B business.please contact us for product prices!
