Lithium Battery 18650 e-bike battery 24 volt 40Ah 24v 36Ah lithium battery

2020-08-12 09:38


Applications:

Electric bicycle, E-bike, EV, Electric scooter, Golf carts, electric bikes, RV, Electric wheelchair
LED lamps, traffic signs, portable small appliances, electric tools, toys, robot etc
Emergency light,dive flashlight,Solar lawn lamp,LED light, lawn mower.

flashlight,outdoor light,Searchlight,tactical light, solar street light
Medical Instrument, Rehabilitation Equipment, Diagnosis Equipment,Medical Testing Device, Medical Monitor
Detecting instrument, Prospecting instrument, Testing instrument., Air/ water testing meter,
Mobile communication equipment , Scaner, Mapper
Power Tool, Wireless Machine, Portable Instrument, POS Machine, Alarm Monitor etc

FAQ
NameValue
Product24V 40Ah Lithium ion battery
ModelAIN18650-7S18P
Rated Capacity40Ah
Nominal Voltage24V
Over discharge protection voltage29.4V±0.05V
Over charge protection voltage21V±0.05V
AC  (1KHz) Impedance New Cell Max.(mΩ)≤120 mΩ
Maximum Continuous Charge Current≤10A can be adjustable
Maximum Continuous Discharge Current10~40A can be adjustable
Maximum Pulse discharge current65~120A can be adjustable
Operation Temperature RangeCharge: 0~45℃,Discharge: -20~60℃
Storage Temperature RangeLess than 1 year: -20~25℃
Less than 3 months: -20~40℃
Storage Temperature RangeLess than 30 Days: -25℃~45℃
Less than 90 Days: -25℃~30℃
WeightApprox  7.1kg
Cycle Characteristicover 800 times
Export2 wires/plugs/connnectors
Dimension80*195*315mm   ,  can be customized

Q1. Can I have a sample order for lithium batteries?

A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.

Q2. What about the lead time?

A:Sample needs 15 days, mass production time needs 25 days

Q3. Do you have any MOQ limit for lithium batteries order?

A: Low MOQ, 1pc for sample checking is available

Q4. How do you ship the goods and how long does it take to arrive?

A: We usually ship by DHL, UPS, FedEx or TNT. It usually takes 3-5 days to arrive. Airline and sea shipping also optional.

Q5. How to proceed an order for lithium batteries?

A: Firstly let us know your requirements or application.

Secondly We quote according to your requirements or our suggestions.

Thirdly customer confirms the samples and places deposit for formal order.

Fourthly We arrange the production.

Q6. Is it OK to print my logo on lithium batteries product?

A: Yes. Please inform us formally before our production and confirm the design firstly based on our sample.

Q7: Do you offer guarantee for the products?

A: Yes, we offer 2 years warranty to our products.

Note: We are a battery manufacturer. All products do not support retail, we only do B2B business.please contact us for product prices!
