Lifepo4 Lithium Ion Battery 48V 100Ah For Backup Power Solar Energy Storage Systems

2022-05-06 09:02

Specification

Model	Uhome-LFP 5000	Uhome-LFP 2400	Uhome-LFP 2500	Uhome-LFP 2600HV
Total energy(DC)	5.1kWh	2.4kWh	2.5kWh	2.56kWh
Usable energy(DC)	4.6kWh	2.2kWh	2.2kWh	2.2kWh
Norminal dis-/charge power	3.0kw	2.75kw	3.75kw	4.6kw
Peak power(only discharge)	6kw for 3s	3kw for 3s	3kw for 3s	3kw for 3s
Constant current(only discharge)	80A	40A	40A	20A
Voltage	48-56Vdc	48-56Vdc	48-56Vdc	96-112Vdc
Norminal voltage	51.2Vdc	51.2Vdc	51.2Vdc	102.4Vdc
Norminal current	60A	30A	30A	15A
Max.charge voltage	57.6Vdc	57.6Vdc	57.6Vdc	115.2Vdc
Weight	45kg	27.5kg	23kg	24kg
Dimension(mm)	500442135mm	500442133mm	50044288mm	50044288mm
Max.recommended DOD	90%
Operating condition	Indoor
Operating temperature	0--45 deg (charge)； -10-- 50 deg (discharge)
WIFI frequency range	2400MHz--2483MHz
Humidity	＜60%(No condensed water)
Pollution degree	3
Over voltage category	II
Cooling type	Natural cooling
Case material	Metal
Color	Black or White
Installation	Wall mounting/Ground Installation
IP rating	IP20
Protective class	I
Max.numbers of parallel or series	8S/4P	8S/8P	8S/8P	6S
Warranty	10years
Life span	>15years
Communication	CAN/RS485
Protection mode	Dual hardware protection
Battery protection	Over-current/Over-voltage/Short circuit/Under voltage/Over temperature
Safety	CE TUV
Hazardous material classification	9
Transportation	UN38.3

The Uhome Energy Storage battery has following advantages

1.Assemblly freely in series or parallel: up to 8S8P(448V326.4kWh)

2.High energy efficiency:Energy efficiency(charge and discharge)>97%

3.High Rate Charge & Discharge:Nominal 0.6C, Max 0.8C

4.More Safety:Dual hardware & Triple software protection

5.Safe and Reliable BMS:Relay design instead of mosfet

6.Long Life:Reliable LFP cells,Cycle life >6000 cycles

7.High Reliability:Key devices(Relay,Fuse) approved by CE and TUV

8.More Smart:With digital monitor system App with WIFI

9.Smart Design & Easy installation：Plug in & off

10.More Quiet:Without fan,more quiet and reduce the fan failure risk

Monitoring Solution

Projects

Packing And Shipping

FAQ

Q1. Can I have a sample order for Battery?
A: Yes, we welcome sample order to test and check quality.Q2. What about the lead time?
A:Sample needs 15-18 days, mass production time needs 25-30 days.Q3. Do you have any MOQ limit for Battery?
A: Depends on different models.For the very regular models,the MOQ is LOW.

Q4. How do you ship the goods and how long does it take to arrive?
A: We usually ship by TNT, UPS, FedEx.... It usually takes 3-5 days to arrive. Airline and sea shipping also optional.

Q5. How to proceed an order for Battery?
A: Firstly,pls let us know your requirements,such as the dimension,continuous&peak discharge current, application of the battery.
Secondly,pls let us know the purchasing quantity and when will your project start.We quote according to the details.
Thirdly customer confirms the price,sample and places deposit for formal order.
Fourthly We arrange the production.

Q6. Is it OK to print my logo on battery ?
A: Yes. Please inform us formally before our production and confirm the design firstly based on our sample.

Q7: Do you offer guarantee for the products?
A: Yes, we offer 12 months warranty to our products.

Q8: How to deal with the faulty?
A: Firstly, Our products are produced in strict quality control system and the defective rate will be less
than 0.2%.
Secondly, during the guarantee period, we will send new batteries with new order to replace the defective.
Thirdly,we will test the defective batteries and make 8D report.We will find out the reason and propose the
improvement measures for future production.

Note: We are a battery manufacturer. All products do not support retail, we only do B2B business.please contact us for product prices!
