4000mAh 12V NiMh Replacement Battery for Neato Botvac Series and D Series Robotic Vacuum 945-0129

2020-12-18 08:02

Technical Data

Electrical Characteristics	Voltage	12V
	Rated Capacity	4000mAh
	Energy	48Wh
	Cycle life	1000+ cycles
	Impedance	Less than 90mΩ
Charge	Standard charge current rate	0.2C(0.8A)
	Rapid charge current rate	0.5C(2.0A)
	Maximum charge current rate	1.0C(4.0A)
	Charge voltage	16.8V±0.2V
	Charge mode	0.2C CC to 12V, then 14V CV,charge current to 0.01C (CC/CV)
	Charge cutoff voltage	14V
Discharge	Standard discharge current rate	0.2C(0.8A)
	Rapid charge current rate	0.5C(2.0A)
	Maximum discharge current rate	10C(40A)
	Peak discharge current rate	20C(80A)
	Discharge cutoff voltage	9V±0.2V
Operating Condition	Charge temperature	0℃ to 45℃(32℉ to 113℉) @60±25% Relative Humidity
	Discharge temperature	-20℃ to 60℃(-4℉ to 140℉) @60±25% Relative Humidity
	Storage temperature	Less than 3 months:-20°C~ 45°C; Less than 1 year:-20°C~ 25 °C
Mechanical	Combination	10S1P
	Dimension	9.57 x 2.05 x 1.18 inches
	Housing	ABS
	N.W.	1.3 Pounds
	BMS	Included
	Power indicator	Included
Color	Black/Blue/Green	Depends on Stocks

This battery is NOT compatible with the D3, D5, D7
NOTE:
* Please fully charge the battery before use. Do not burn or puncture the battery.
* When you don't use Neato, please place it on the charging base- avoid sun and heat, and place it on a flat surface.
* Disconnect the battery or turn off the machine when storing Neato. Please keep the cell under half charge statue, neither fully charge or discharge if long-term storage.
* Charge the battery as soon as possible when your battery is being drained. If the battery is low and the LED is amber or
blinking amber, charge the battery as soon as possible.
* Do not mix cells of different manufacture, capacity, size or type within a battery.
* During long-term storage, the battery should be charged and discharged once every 3 months.

Replacement & Compatible

Replacement for battery P/N	945-0129
Compatible with Tool Models	Compatible With: * Replace Part No.: 945-0129 * Neato Botvac 70e * Neato Botvac 75 * Neato Botvac 80 * Neato Botvac 85 * Neato Botvac D75 * Neato Botvac D80
