Energy Storage LiFePO4 Battery 12V 80Ah Solar Batteries for Power Supplies

2021-01-12 06:32

Specification

ITEM		Specification
Nominal Capacity		80AH
Rated voltage		12V
Energy density (Wh/kg)		85
Internal Resistance		15mΩ
Charge (CC-CV)		1C
Charge (float)		3C
Max. charging current		20AH
Standard. charging voltage		14.6V
Recommended charging current		0.5C
Max. continuous discharging current		1C
Max.pulse discharging current(30seconds)		3C
Recommended discharging current		100AH
Max. End-off discharged voltage		10V
Self discharge rate (monthly)		3%
Dimension		350175220mm
Weight (Approx.)		14kg
Working temperature	Charging	0℃-35℃
	Discharging	-20℃-45℃
Storage temperature	In one month	0℃-25℃
	In six months	0℃-35℃

Key Features
♦Longer Cycle Life : Offers up to 20 times longer cycle life and five times longer float/calendar life than lead acid battery , helping to minimize replacement cost and reduce total cost of ownership
♦Lighter Weight : About 40% of the weight of a comparable lead acid battery . A " drop in" replacement for lead acid batteries
♦Higher Power : Delivers twice power of lead acid battery ,even high discharge rate, while maintaining high energy capacity
♦Wider Temperature Range : -20℃~60℃
♦Superior Safety: Lithium Iron Phosphate chemistry eleminates the risk of explosion or combustion due to high impact overcharging or short circuit situation
Applications :
♦Wheelchairs and scooters
♦Solar/wind energy storage
♦Back-up power for small UPS
♦Golf trolleys & buggies
♦Electric bikes
